Authorization Code Flow¶

The Authorization Code grant type is used by web and mobile apps. It differs from most of the other grant types by first requiring the app launch a browser to begin the flow. The application first needs to decide which permissions it is requesting, the scope, then send the user to a browser to get their permission.

At a high level, the flow has the following steps:

• The application opens a browser to send the user to the OAuth server

• The user sees the authorization prompt and approves the app’s request

• The user is redirected back to the application with an authorization code in the query string

• The application exchanges the authorization code for an access token

All these steps above are managed by F5 XC secure access, exactly by the NGINX gateway, as a relying party, that free up the application about implementing the authentication mechanism.

Relying party¶

With F5 XC Secure Access, both the client and the NGINX gateway communicate directly with the IdP at different stages during the initial authentication event.

NGINX Plus is configured to perform OpenID Connect authentication:

• 1. Upon a first visit to a protected resource,

• 2. NGINX Plus initiates the OpenID Connect authorization code flow and redirects the client to the OpenID Connect provider (IdP).

• 3-5. The IdP verifies the identity of the end-user.

• 6. When the client returns to NGINX Plus with an authorization code,

• 7-8. NGINX Plus exchanges that code for a set of tokens by communicating directly with the IdP.

• 9. The ID Token received from the IdP is validated. NGINX Plus then stores the ID token in the key-value store, issues a session cookie to the client using a random string, (which becomes the key to obtain the ID token from the key-value store)

• 10. and redirects the client to the original URI requested prior to authentication.

• 11. Subsequent requests to protected resources are authenticated by exchanging the session cookie for the ID Token in the key-value store.

• 12. JWT validation is performed on each request, as normal, so that the ID Token validity period is enforced.

For a more detailled diagram on OpenID Connect and NGINX, please visit the repository here.

Validating JWT signature¶

NGINX Secure Access gateway is validating the JWT signature. The signature is verified (for JWS) or payload is decrypted (for JWE) with the JSON Web Key Sets (JWKS) URIs of the allowed IdPs.

Validating the Claimed Scope and Audience¶

NGINX Secure Access gateway provides support for JWT authentication and sophisticated configuration solutions based on the information contained within the JWT itself. The App SQUAD defines fine grained scope and Audience as required in the Public LB routing policy, for example:

• per App: Public LB default HTTP route,

• per Service: Public LB specific HTTP route that matches a Host

• per micro-service: Public specific HTTP route that matches a PATH

• per HTTP method GET, POST, UPDATE, DELETE to filter Create, Read, Update, Delete (CRUD) rights

Then the NGINX gateway will compare the validated JWT against the expected scope defined in the customer header, x-my-scope here.

Leveraging JWT Claims as User Identifier¶

One of the primary advantages of JWTs as authentication credentials is that they convey “claims”, which represent entities associated with the JWT and its payload (its issuer, the user to whom it was issued, and the intended recipient, for example). After validating the JWT, NGINX gateway and XC LB has access to all of the fields present in the header and the payload.

For example, Secure Access is leveraging JWT Claims to Identify a User, and track their activities with XC Malicious User, and Rate Limiting per Identified User.

In this example below, we’re also using claim-based variables to provide API rate limiting per API client, instead of per IP address. This is particularly useful when multiple API clients are embedded in a single portal and cannot be differentiated by IP address.

Detection¶

Malicious User is part of the F5 XC User Behavior Analysis that detects suspect behavior based on watching several dimensions:

Mitigation¶

If a client tries to access resources with insufficient privileges, NGINX gateway will return a 401 response code. After several attempts (10 by default), a security event will be raised and a step-up challenge will be send. The system tags the users into threat levels High, Medium, and Low.

If the client that manages to resolve challenges and tries to access resources with insufficient privileges, then this client will be blocked. The system automatically lower the score when there is no malicious behavior detected for this Identified User for a certain period of time. This is known as the Cooling Off Period. This period indicates how long it takes to lower from High threat level to Low. The system executes a score decay mechanism over a period of time for this to happen.

User Identifier¶

The User is identified by a Claim of its JWT, email for example. If not present, the Bearer Token is used, else a Secure Access cookie. The User Identifier is customizable by the App SQUAD and per Application (LB).

Shared Services¶

Secure Access is deployed as a Shared Service that can be consumed by any Application namespace.

From a app Namespace, Landing-Zone-A for example, the Applicative Squad is free to consume the Secure Access shared services : - oAuth/OIDC authentication - or/and JWT validation

These services can be consumed:

• per application (XC LB)

• per service (DNS domain)

• per micro-service or API Group (HTTP PATH).

For example the private part /my-account of a web site can require to authenticate user access.

How to consume a Shared service?

In the Public HTTP LB (in blue in the diagram), a HTTP Route is configured to forward the traffic to a service of the Secure Access gateway. Once authenticated, the Secure Access gateway forwards the request back to the Application namespace, i.e. to the internal HTTP LB (in pink in the diagram).

### ToDo change the Keys to update Public LB

Secure Access GateWay¶

The oAuth/OIDC authentication and the JWT validation are featured by a NGINX gateway.

F5 XC, as a Multi-Cloud Networking Software (MCNS), allows to insert any container based service in the data-path, named Container as a Service (CaaS). For example, an NGINX gateway.

The whole configuration of the Secure Access GateWay is stored in NGINX One console. At the container startup, NGINX Agent is retrieving the Secure Access GateWay configuration from NGINX One console.

Therefore, the Secure Access GateWay is a Platform as a Service (PaaS), based on supported NGINX+ containers and managed by NGINX One console, that makes easy to manage NGINX instances across locations (Regional Edge, Customer Edge or other platform factor). The console lets you monitor and control your NGINX fleet from one place:

• read or/and update the configuration

• track performance metrics

• identify security vulnerabilities

Dynamic configuration¶

Some parts of the NGINX configuration is dynamic to allow the Application to specify:

• the selected Identity Provider in the allow list of the company

• the Application ID to use, for OIDC

• the granted Scope and Audience to clients

These specifications (IdP, App-ID, Scope, Audience) are set as custom HTTP headers in the Public HTTP LB, exactly per HTTP Route, managed by the applicative Squad.

HTTP Route:

Custom Headers

Variable in NGINX configuration

Demo video¶
